Beverage / Mineral Water PLC Based Automatic Bottle Filling

Water Treatment/ Automatic Water Filling Machinery Line/Rinsing Filling Capping Machine

Quick Detail:

• Model: CGF32-32-12 3 in 1 Monoblock
• Place of Origin: Zhangjiagang city, China near Shanghai
• Brand: BJM
• Application: Pure water/Mineral water/Drinking water/Non-carbonated water/Beverage/Codiment etc
• Rinser Head: 32pcs
• Filler Head: 32pcs
• Capper Head: 12pcs
• Capacity: 10,000 to 12,000 bottles per hour
• Bottle Type: 200ml to 1.5L/2L to 10L
• Cap Type: Screw cap, Pressing Cap, Sport cap
• Bottle Type: PET/PP/PE/HDPE Plastic Bottle
• Bottle Shape: Round/Square/Rectangular/Irregular
• Full line including: Bottle Feeder, Rinser-Filler-Capper 3 in 1 machine, Lamp Checker, Labeling Machine, Film Shrink Machine/Carton Packing Machine

Specifications:

Description:

1, The water filling machine is used in filling mineral water, purified water, still water etc in bottles made of polyester and plastics. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.

2, The rinser, filler and capper 3 in 1 job can be finished by one machine automatically, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, and bottle changing is easier.

3, The machine operation is faster and more stable because the micro gravity filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.

4, The full line water filling equipment includes: Bottle Feeder, Air Conveyor, Washing-filling-capping 3 in 1 machine, lamp checker, label shrinking machine, code printer, hot shrink packing machine/carton packing machine and conveyors. It is a full automatic production line.

5, Spares contact with the liquid are all of excellent stainless steel or food level plastic. The electric system is of international brand and achieves the national food sanitary standard.

1. Main motor Siemens
2. Liquid level sensor France
3. Pump South Pump(China Famous Brand)
4. Touch screen Taiwan
5. PLC Mitsubishi
6. Inverter Mitsubishi
7. Photoelectric switch Omron
8. Contactor, Circuit breaker Snyder France
9. Bearing NSK Japan
10. Seal ring U.S
11. Material contact valve, tank, pipe SUS304/316L

All Parts we can custom made for requirement for each customer, like Grundfos Pumps, Sew Motor, Festo Electric Appliance, etc.

Competitive Advantage:

• 1, Water Filling Machine uses neck handling by grippers bottle transmission,
• 2, Fully automatic rinsing, filling and capping by PLC control;
• 3, No bottle no rinsing;
• 4, International brand Electrical components;
• 5, All material contact parts are made of qualified stainless steel, wearable, stable with less malfunction;
• 6, Using starwheel as its drive mechanism, which realize automatically rinsing, filling and capping.
• 7, We have long-term cooperated factory manufacturing blowing machine, so we have provide full line prodcution from blowing machine, water treatment, water filling and packing system.

Benjamin Machinery pays great attention to technology, such as beer processing and filling technology, high-viscosity filling technology, glass bottle water filling technology. And we will try our best to satisfy your requirement, your message will be highly appreciated. Welcome to Benjamin Machinery.
