Lightweight And Convenient Prefab Steel Frame Modular Homes
  • Lightweight And Convenient Prefab Steel Frame Modular Homes
Lightweight And Convenient Prefab Steel Frame Modular Homes

Lightweight And Convenient Prefab Steel Frame Modular Homes

Min. Order:
1
Min. Order:
1
Delivery Time:
30 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Yangzhou,Jiangsu,China
Product Description
Product Description



Lightweight and Convenient Prefab Container Homes Fast Assembling Customer Designed


Descprition

Prefab container homes is on the base of 20 feet container. The houses becoming one of the fastest growing products in the housing market, but make sure you do your research into the type of systems available to suit your particular site and your own personal taste.And the strong firm structure is made of galvanized steel frame, so the life time is more than 30-50 years.

Application

Preab container home is widely applicated for office, accommodation, hotel, hospital, commercial kiosk, parlor, bedroom, study room, locker room, ablution room, school, shower room, kitchen, dining room, works camp, exhibition, dormitory, villa, carport, house, coffee room, booth, sentry box, guard house, shop, toilet, warehouse, workshop and so on.

Competitive Advantage

  1. Uniform shape and size make a big project seems more stately.
  2. Simple structure make installing job easier and quicker.
  3. Container shape frame make the house strong and solid enough to insure the safety.
  4. Freely combination suit for many kinds using as you want.
  5. Fireproof, heat/cold-insulated, non-shrinking and enlarging work size with little pollutions.
  6. Life time is more than 15year.

Specifications:

Dimension(mm)&Weight(kg)

Type

External

Internal

Weight (kg)

Length

Width

Height (package)

Height (assembled)

Length

Width

Height

20’

6055

2435

648/864

2591/2790

5860

2240

2500

from 1850

Floor

Steel frame

- made from cold rolled, welded steel profiles, 4 mm thick

- 4 corner casts, welded

- 2 fork lift pockets (except 30’) - distance 1200mm

(internal clearance of fork lift pockets: 240×80 mm)

- steel cross members, thickness=2mm

Insulation

- 100 mm thick Rock Wool

Subfloor

- 0.5mm thick, galvanized steel sheet

Floor

- 18mm plywood board

- 1.8mm PVC floor

- flammability class B1 - hardly combustible

- smoke density class Q1 - low smoke emission

- wear resistance factor: T level

Insulation

Rockwool

- density:120kg/m3

- flammability class A- non combustible

- smoke density class Q1 - low smoke emission

- certificated: CE & GL

NeoporR

- density:18kg/m3

- flammability class B1- non combustible

- smoke density class Q1 - low smoke emission

- certificated: CE & GL

Coatings (Optional)

DecoCoating

Special coating can be applied on top of sandwich wall panel and make the external wall surface looks like plastering finishes or timber finishes. That makes the container house cozy and less industry look.

Assembly Process

Easy to be Assemble and disassemble. Four workers can complete one unit in half day.
