PET Bottle Hot Filling Machine , Automatic 3 in 1 beverage

PET Bottle Hot Filling Machine , Automatic 3 in 1 beverage Filling Line

Quick Detail:

Driven Type: Electric

Voltage: 110/220/380V

Power: 10.5KW

Place of Origin: Jiangsu, China (Mainland)

Brand Name: Renda

Dimension(L*W*H): 2900*2500*2900mm

Weight:9.2T

Certification: CE,ISO

Processing: bottle packing machine

Suitable Bottle: 0.25-2L

Material: stainless steel

Warranty: 1 year

After-sales Service Provided: Engineers available to service machinery overse

Description:

1.Famous Mitsubishi brand PLC and Touch-screen Control Panel (man-machine interface) are adopted in this Fruit Juice Hot Filling Machine, easy operate & working steadily.

2.Famous Omron brand electric parts adopted in this Fruit Juice Hot Filling Machine, ensure the whole system heavy duty running.

3.The Fruit Juice Hot Filling Machine uses food grade stainless steel rinsing pump & filling pump, reliable & sanitary.

4.The Fruit Juice Hot Filling Machine uses 304 stainless steel construction, which gives excellent appearance and can be easily disinfected.

5.The motor speed of Fruit Juice Hot Filling Machine is controlled by a variable-frequency-drive, so the product rate of rinsing filling capping machine can be adjusted easily.

6.The suspending design of Fruit Juice Hot Filling Machine allows the maintenance to be performed easily due to fewer moving parts.

6.Excellent design to make Fruit Juice Hot Filling Machine easily when needs to change machine height when bottles sizes are changed.

8.The Fruit Juice Hot Filling Machine is no bottle no filling; no bottle no capping, filling volume adjustable.

Applications:

Applicable for: fruit juice, tea beverage, functional beverage etc.

Applicable container: various PET bottles with different capacities and shapes

Bottling system: gravity bottling, low vacuum bottling etc.

Production capacity: 15000BPH—18000BPH

Specifications:

Competitive Advantage:

--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles

--Precise control bottling fluid level, powerfully prevent air bubble

--Sanitary class circulating pipe assures the temperature when bottling

--Capping and clamping technology
