Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Zhangjiagang China |
|---|
Plastic 17.5KW Bottle Blowing Machine / Semi Automatic Blow Moulding Machine
Quick Detail:
- Condition: New
- Application: Bottle
- Plastic Processed: PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Model Number: CM-8Y
Description:
1. Solenoid Valve (Pneumatic Valve for Mold Clamping): Korea, PMC
2. High Pressure Valve (Blowing Valve): China
3. Seal & Stretch Cylinder: China
4. Clamping Cylinder: China
5. PLC: Delta, Taiwan
Applications:
CM-8Y Semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 0.1L to 2L.
Specifications:
|
Model |
ITEM |
|
CM-8Y |
|
Container |
Product material |
/ |
PET |
|
Volume |
L |
0.1-2 |
|
|
Theoretical output |
pcs/h |
1400-1800 |
|
|
Preform length |
mm |
≤350 |
|
|
Preform inner diameter |
mm |
φ5-38 |
|
|
Mould |
Max.mould plate Diameter(L*W) |
mm |
350*380 |
|
Max.mould thickness |
mm |
180 |
|
|
Clamping force |
kn |
45 |
|
|
Mould opening stroke |
mm |
160 |
|
|
Machine size and Weight |
Main machine (L*W*H) |
cm |
1600*600*1610 |
|
Main machine weight |
kg |
500 |
|
|
Heater (L* W*H) |
cm |
1870*630*1450 |
|
|
Heater weight |
kg |
250 |
|
|
Power |
kw |
17.5 |
Competitive Advantage:
- Save Cost
- Stable Quality
- Save Place
