Basic Info

Place of Origin:	China

Product Description

7000BPH Automatic Water Filling Machine With CGF16-16-5

Quick Detail:

Name	Water filling machine, water bottling machine, water filler, water filling equipment	Brand Name	StepChina
Function	Bottle washing, water filling, bottle capping	Material	Stainless steel 304
Model	CGF16-16-5	Usage	Bottled water production
Capacity	7000 B/H for 500ml	Maxium bottle	2500ml

Description:

This product is a kind of 3-in-1 unit water filling machinery for producing potable drinking water like pure water, mineral water etc. The device incorporates rinsing, filling and capping into one and is a kind of full-automatic equipment. It is suitable for producing PET and plastic bottled mineral water and purified water.The equipment is fitted with advanced Mitsubishi programmable PLC to control the operation and cooperated by frequency converter of the main motor; it makes the operation more stable and reliable. The photoelectric sensor is used to detect operating conditions of each section, which makes the operation of this equipment highly automatic and convenient.

Specifications:

Name	Rinsing, filling and capping machine
Model	CGF 16-16-5
Material	Stainless steel 304
Production capacity	7000B/H (500ml)
Detail specification
Number of rinsing heads	16
Number of filling heads	16
Number of capping heads	5
Applicable bottles	PET bottle,plastic bottle
Bottle diameter	Φ55-110mm
Bottle Height	186-310mm
Bottle Volume	200-2500 ml
Applicable caps	Plastic screw cap
Total power	1.5 Kw
Weight	2000 Kg
