Dental X-ray Equipment, Wall Hanging

Get Latest Price

Payment Type:: T/T, L/C or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C or Western Union

Product Description

Wall hanging dental type

Specifications:

Power: 220V AC ±10%
Socket: internal three-pin/European three-pin
Maximum power: 900VA
Rated current: 4A
Fuse: 6.3A
Radiation focus: 0.8mm
Tube-head voltage: 70kV ±10%
Anodal current: 7mA ±15%
Anodal angle: 19°
Loading circle: 1/60
Half-value layer: 70kV 1.6mm, Al
Proper filter: ≥2.1mmAl
Radiation leakage: 1m＜0.007m, Gy/h

Technical features:

Clear picture, high efficiency, international advanced technology
Low radiation: radiation leakage is only 1% of state regulations
Microcomputer control system, exposure parameters will be quickly and accurately formed at one button push
Easy operation
Pictures could be rinsed in bright room, imaging in minute provide much convenience to dentists
Seat is free to lift up and down
Dental digital sensors could fit this X-ray equipment
Do not occupy any ground, save space for users
Rotating arm is stable, reliable, durable and easy to use
Low pressure alarm, high pressure alarm, automatic failure detection alarm

Precise time control system

Accuracy of exposure time is 0.01s and is showed on LED as figures

Any alarms will show precisely due to high-tech microprocessor

Horizontal focus, clearest image can be acquired easily

After repeated choosing and aging of Dyson ray tube, performance is more steady and life is extended more than 35%

Microcomputer chip and important electrical components are imported

Intelligent microcomputer exposure control, line-calories test make resolution reach international advanced level

Closed in no radiation, you got nothing to worry about radiography operation

Tiny X-ray sources and tube cover are strictly sealed by lead plate

In condition of open exposure, leaking rays over 1.5m away from X-ray sources is 68 times lower than national standards, even lower (0 to 0.3mR/h) than human body security value 0.5mR/h

Do not need X-ray protection room and protect patient's and doctor's health truly

Power: 220V AC ±10%

Socket: internal three-pin/European three-pin

Maximum power: 900VA

Rated current: 4A

Fuse: 6.3A

Radiation focus: 0.8mm

Tube-head voltage: 70kV ±10%

Anodal current: 7mA ±15%

Anodal angle: 19°

Loading circle: 1/60

Half-value layer: 70kV 1.6mm, Al
