Tinned Cu Wire Braiding PVC Sheathed Data and Computer Cable with UL PE Insulation

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Applications:

Used in flexible or stationary applications under low mechanical stress with free movement without any tensile stress, loads or forced movements in dry and damp conditions
Commonly used for interference free transmissions of data and signals over long distance
Specially designed for fast and cost effective connections using solder-free connection techniques

Construction:

Conductor: stranded bare copper conductors
Insulation: PE
Cores: twisted in pairs
Wrapping: plastic foil
Screen: tinned copper wire braiding, 85%
Outer sheath: PVC

Technical data:

Nominal voltage: 300V
Test voltage: 2000/1000V

Temperature range:

Fixed: -30 to +80°C
Flexible: -5 to +70°C

Standards/material properties:

Fire performance: IEC 60332-1
Approval: CE

Used in flexible or stationary applications under low mechanical stress with free movement without any tensile stress, loads or forced movements in dry and damp conditions

Commonly used for interference free transmissions of data and signals over long distance

Specially designed for fast and cost effective connections using solder-free connection techniques

Conductor: stranded bare copper conductors

Insulation: PE

Cores: twisted in pairs

Wrapping: plastic foil

Screen: tinned copper wire braiding, 85%

Outer sheath: PVC

Nominal voltage: 300V

Test voltage: 2000/1000V

Fixed: -30 to +80°C

Flexible: -5 to +70°C
