Product Description

Application:

TWTCS cable typical applications include carriage wiring, terminal boxes, power supply to various systems and ground connections inside railway rolling stock at fixed or sporadic moving installations

Construction:

Conductor: stranded tinned copper acc. to IEC 60228 cl.5
Insulation: electron beam crosslink LSZH compound
Screen: copper wire screen
Outer sheath: electron beam crosslink LSZH compound
Colour: black

Technical data:

Nominal voltage: 600/1000V AC, 900/1500V DC
Test voltage: 4000V, 50Hz, 5min
Temperature range: -40°C - + 125°C
Short circuit: +280°C/5s

TWTCS cable typical applications include carriage wiring, terminal boxes, power supply to various systems and ground connections inside railway rolling stock at fixed or sporadic moving installations

Conductor: stranded tinned copper acc. to IEC 60228 cl.5

Insulation: electron beam crosslink LSZH compound

Screen: copper wire screen

Outer sheath: electron beam crosslink LSZH compound

Colour: black

Nominal voltage: 600/1000V AC, 900/1500V DC

Test voltage: 4000V, 50Hz, 5min

Temperature range: -40°C - + 125°C

Short circuit: +280°C/5s
