Bender for Pipe (Factory Price)

Bender for Pipe(Factory Price)


Usage and Features:
It is used to produce a series of bending tube, furniture tube, sports equipments tube, air material tube, tube and all other bending tube etc.

-Se-automatic and automatic function;
-With auto-sensor and indicator, avoid operation mistake and break machine;
-Completed with limited protection system;
-Built with urgency stop switch of the mobile foot pedal;
-Completed with cooling system;
-With fast change mould device, operation easy and prompt;
-Adapt operation control panel, bending angle and quantity could display.


Model: A75 NCB
Max. Bending Diameter× Thickness(mm)75mm*3mm
Max. Bending Radius(mm)35mm-250mm
Bending Angle0-190
Max. Feeding Length(mm)2600mm
Working Table Height935mm
Mould Height35mm
Clamp Pipe Stroke52mm
Max. Length Stroke70mm
Hydraulic System Motor4kw
Total Power4kw
Oil Tank Capacity120kg
Max. Pressure150kg
Voltage380v/50Hz
Machine Dimension(LxWxH)3600*1000*1150mm
Machine Weight2500kg
