Foil Roll Slitting and Rewinding Machine for Fruit Food

Foil Roll Slitting and Rewinding Machine for Fruit Food



Features and Usages:
Our FM-F600 Semi-auto Aluminum Kitchen Foil Roll Rewinding Machine adapts advanced Taiwan technical and electric parts; It's a ideal machine for catering foil roll, kicthen foil roll and household foil roll rewinding.

1. With auto feeding aluminum foil speed control, alignment and adjustment;
2. Fast speed up to 8m/s, its ideal machine for long foil rolls rewinding;
3. Feeding, rewinding automatically; Core loading with hand;
4. Adopts Frequency Converter, Speed can be displayed on the Control Board;
5. With automatic stop switch;
6. Automatic counting system, length can be set;
7. Low cost, high productivity and user-friendly;



Technical Data:

Model----------------------------------FM-F600
Material thickness --------------------0.009-0.025mm
Maximum Unwinding Width----------------600mm
Maximum Unwinding Diameter-------------800mm
Maximum Rewinding Width----------------600mm
Mother Core Diameter-------------------76mm/152mm (option)
Finished Product Core Diameter---------30mm/35mm/38mm (option)
Length of production-------------------50m-600m
Production Speed-----------------------0-500m/min
Power of Motor-------------------------3.0 Kw
Machine Weight-------------------------850 Kg(Around)
Machine Dimension (LxWxH)--------------1900X1750X1000mm
