Ultrasonic Flaw-Detection Machine

Portable Digital Ultrasonic Flaw Detector machine FD201B
Ultrasonic detector, NDT, UT, ndt test
DAC, AVG curves
High-speed capture and very low noise
Gate and DAC alarm; Acoustic-Optical alarm
Solid metal housing (IP65)
High contrast viewing of the waveform from bright
Powerful PC software and reports can be export to excel.
Automated display precise flaw location (Depth d, level p, distance s, amplitude, sz dB, )
Automated switch three staff gauge ((Depth d, level p, distance s)
Convenient to make and use DAC and AVG to evaluate the echo, the curve can be modified and compensated
Ten independence setup, any criterion can be input freely, we can work in the scene without test block
Big memory of 300 A graph
Automated gain and gain scan, automated echo degree
Peak hold and Peak memory
Powerful PC software and reports can be export to excel
The embedded software can be online updated
Li battery, continue working time up to 10 hours
Display freeze
Lock and unlock function of system parameters
Dormancy and screen savers
Electronic clock calendar.
Two gates setting and alarm indication.
Additional functions
AWS
6dB DAC
Standard delivery
Main unit
2.5MHz-20 straight probe
4MHz-8X9mm, 60 degree angle probe
4A/9V power adapter
Probe connection cable (BNC to BNC)
Probe connection cable (BNC to LEMO
USB2.0 RS232 converter
Instruction manual
Calibration certificate.
Carrying case.
Additional accessories
Data managing software
Data managing cable RS232
Leather bag
All kinds of angle and straight probe, double crystal probe at any size with frequency 0.5— 15MHz
Connection cable for probe LEMO and BNC
Lithium ion battery.
Power adapter (4A/9V).
Test block V1
Test block V2.
Test block DAC, ASME etc.
