Free Cooling System FC-2048

Get Latest Price

Payment Type:: L/C, T/T, Negotiable

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	L/C, T/T, Negotiable

Product Description

Input voltage: 48V DC
Maximum heat transmission at DT 7: 3.1kW
Maximum heat transmission at DT 5: 2.5kW
Power consumption (at full speed): 55W
Power consumption (at min speed): 20W
Maximum current: 1A
Storage temperatures: -45 to 75° C
Side cabinet protection degree: IP55
Working temperature range: -25 to 75°
Noise at full speed: <60dBA (meets ETSI 300 753)
Noise at beverage: <55dBA (1 meter away)
Noise at night mode: <50dBA (1 meter away)
Alarm at over-temperature or fan fail: Dry contact
Temperature control: Micro-controller electronic
Fan airflow: 1, 448m³ /hour
Overall housing: Metal sheet
Filter: G4 thermo conductive material
Plastic: Halogen-free UL94-V2
PCB: UL94-V0
Total weight of all units: 20kg
