Afsd Series Pm Precision Sizing Machines

AFSD series PM Precision Sizing Machines

The AFSD series PM precision sizing machines are powder metal presses used in large-scale series production: The manufacture of metallic powder, forming and sintering. This power metallurgy machine is required for the sub-step of the forming operation to press the powder mass into a die.
Below are the specifications of thepowder metal presses:
1. The closed type integral welding body of this power metallurgy machineeliminates the press angle deformation phenomenon, improves the processing precision and extends the service life of die;
2. With eight-side long rectangle guides, high precision enable stable running and high precision possible;
3. Dry pneumatic friction clutch produces low noise and makes it easy access to maintenance;
4. With hydraulic overload protection device, power metallurgy machine has the ability to operate automatic emergency stop, thus makes press and die protection safety and easy to use;
5. It also has automatic oil lubrication system with a circuit alarm function, which ensures that the machines run smoothly;
6. With die height automatic control as well as digital display device, the powerpowder metal pressesare convenient in mold adjustment;
7. PLC electric centralized control, with emergency stop, inching, single, continuous operation specification;
8. Optional photoelectric protection includes a drive output shaft, automatic feeding as well as an air cushion device.
