Universal Radial Milling Machine M3T, M4T, M5T, M6T
Work Table width is increased for MT SERIES
Dimensions:
M3T: 320× 1270
M4T: 320x1370
M5T: 320x1470
M6T: 320x1470
Advantages:
1, The machine is of excellent configuration with wide working range and small area requirement. Head swivel angles are 90° Left/right and 45° Front/back. Ram not only is movable in front and back direction but also can be rotated 360° Horizontally to greatly extend the machine's working range.
2, The machine body is made of SC250 Casting with maximum rigidity and reliability. Spindle is made of Chrome Molybdenum Steel, tempering and carburizing heat treated. Spindle is assembled with precision Ball Bearing that provides wide cutting range and high precision.
3, Three axes Nuts on the screw are made of PBC-2 for maximum wear resistance and long lifetime.
4, X, Y, Z axes slideways are laminated with wear resistant material
5, Working table and slideways are treated with inductive surface hardening and precision ground for maximum wear resistance. Equipped with manual lubrication system for concentrative lubrication on work table and knee.
6, R8, NT30, NT40 Spindle tappers are available.
