Universal Knee Type Milling Machine (M6125A)

Universal Knee Type Milling Machine (M6125A)

Table size: 250*900mm
Longitudinal travel: 500mm
Cross travel: 165mm
Vertical travel: 300mm
Max. Rotary angle of table: ± 45º

Main Characteristics & Application:
Model M6125A Universal Knee-type Milling Machine is a minitype machine, used for milling flat, inclined face, vertical surface and slots by employing disc cutters, angular cutters, formed cutters and face metal milling cutters. When mounted with the vertical milling attachments, the machine will be able to perform milling operations in various directions. When mounted with the rotary table, helix groove and ring formed can be milled. With the universal dividing head, the machine will be able to cut spur gear M=3mm, helical gears, bevel gears, etc...

Owing the versatile applications, the machine is well suited for repair shops and tool rooms for single piece and lot production.
