CNC Horizontal Large Lathe (T1400/1500&T1600/1500)

CNC Heavy Large Lathe (T1400/1500&T1600/1500)

Specifications:
Max. swing over bed: 1400/1600mm
Max. swing over carriage: 990/1190mm
Maximum length of workpiece: 1500-10000mm
Spindle bore: Φ130 mm


This machine has the following features:

Mateched with FANUC SIGMENS or NC system high-reliability because of its STD totalline strnc-tion, CRT showing, line and circle in-terpolation.

2 axle closs-circle control, AC servo motor, Semi-closed loop control system. High-strength casting  bed with high-frequency chilling and priecise grinding.

Slidewaygluded low-fricton plastics.

Spindle with frequening converter and stepless variable drive.

Suited for cutting workpieces which have various shapes and sizes.

Longitudinal and cross feeds are effected by servo motor drive through ball screws.

Φ 130mm spindle bore, short taper positioning spindle nose for high precision and rigidity.

Centralized lubrication system in headstock for less heating and heat distortion.

Supersonic frequency hardened guide ways to ensure high precision and long service life.
