Gap Bed Turning Lathe Machine (T500/1000)

Gap Bed Turning Lathe Machine (T500/1000)

Main parameters:
Max. Swing dia. Over bed: φ 500
Max. Swing dia. Over carriage: φ 310
Distance between centers: 1000/1500/2000/3000mm
Max. Swing over gap: 720mm
Spindle bore: φ 80

This machine has the following features:

1, The guide ways and all gears in the headstock are hardened and precision gound.
2, The spindle bore size is 80mm. The spindle system is high in rigitidy and accuracy.
3, Rapid feed structure is available on Apron.
4, Clutch in headstock makes the lathe more attactive.
5, The machines have powerful headstock gear train, high rotating accuracy and smooth running with low noise.
6, An overload safety device is provided on the apron.
7, The steel, casting iron, nonferrous metals and non-metal materials can be processed by the lathe.


Standard accessories:
Ø 250 3jaw chuck
Face Plate
Morse reduction sleeve M. T. NO. 7/5
Centers M. T. NO. 5
Wenches
Operation manual


Extra Equipment(at extra cost):
Ø 320 4-jaw chuck
Ø 250 Drive plate
Follow rest
Steady rest
