Bench Turning Lathe Machine (T330/750 T330/1000 T360/750 T360/1000)

Bench Turning Lathe Machine T330/750 T330/1000 T360/750 T360/1000


Swing over bed: 330/360mm
Swing over cross slide: 198/212mm
Spindle Hole: 38mm
Bed length: 1248/1655/1363/1655mm
Admits between: 750/1000mm

This machine has the following features:
1, Precision ground and hardened bedways
2, The spindle is supported with precision roller bearings
3, Head stock gears are made of high quality steel ground and hardened
4, Easy operating speed change levers
5, Removable gap is provided for larger diameter work
6, Spindle speed range 70-2000 RPM
7, Three differnet lengths bed are available
8, Easy operating gear box has various feeds and thread cutting function
9, ASA D1-4 camlock spindle nose
10, With or without cabinet according to requirenent


Standard accessory
1. Sleeves MT 5/3
2. Centers (Dead center MT. 3 Alloy center MT. 2)
3.3 Jaw chuck 1 plece
4. V-belt(A762 2 pieces)
5. Metric changing gears (m=1.25...8 pieces)
6. Tool box and tools 1 set 1 set
7. Oil gun 1 piece
Extra Equipment(at extra cost)
1.4-jaw chuck(200mm) 1 piece(8")
2. Face plate(300mm) 1 piece(12")
3. Steady rest 1 piece
4. Follow rest 1 piece
5. Foot stand
6. Foot brake (5.6 special ordering)
