MSVLA
AMS-Military grade Cable & Wire Identification Sleeves
Description
MSVLA series is the military grade cable and wire identification sleeves, which is made of cross-linked environmentally friendly polyolefin bombarded by high-power electron beam with electronic accelerators to meet requirements of high end markets where highly reliable cable& wire identification is required. It accords to Classes 1 and 3 of AMS-DTL-23053/5 half-hard high molecular materials. For this product, both 2: 1 and 3: 1 shrink ratio are available on your request.
Features
Military grade, lightweight, well suited for aerospace vehicles, tank, and submarines identification purposes
High temperature resistant(temperature rating 135° C/275° F)
Highly flame retardant, VW-1
RoHS compliant
Highly reliable and permanent identification
Thermo-sensitive, quick recovery
Computer-printable, any characters and logo are easy to design
Rated Temperature
Continuous operating temperature: -55° C~135° C/-67° F~275° F
Min. Shrink temperature: 85° C/185° F
Full recovery temperature: 115° C~200° C/239° F~392° F, 8~3minutes
Max. Storage and transportation temperature: ≤ +50° C/122° F
Standards
Meets AMS-DTL-23053/5, compatibility: UL224
Color code soundness: SAE-AS 81531 and MIL-STD-202F/215J
Dimension(2: 1)
AMS-Military grade Cable & Wire Identification Sleeves
Description
MSVLA series is the military grade cable and wire identification sleeves, which is made of cross-linked environmentally friendly polyolefin bombarded by high-power electron beam with electronic accelerators to meet requirements of high end markets where highly reliable cable& wire identification is required. It accords to Classes 1 and 3 of AMS-DTL-23053/5 half-hard high molecular materials. For this product, both 2: 1 and 3: 1 shrink ratio are available on your request.
Features
Military grade, lightweight, well suited for aerospace vehicles, tank, and submarines identification purposes
High temperature resistant(temperature rating 135° C/275° F)
Highly flame retardant, VW-1
RoHS compliant
Highly reliable and permanent identification
Thermo-sensitive, quick recovery
Computer-printable, any characters and logo are easy to design
Rated Temperature
Continuous operating temperature: -55° C~135° C/-67° F~275° F
Min. Shrink temperature: 85° C/185° F
Full recovery temperature: 115° C~200° C/239° F~392° F, 8~3minutes
Max. Storage and transportation temperature: ≤ +50° C/122° F
Standards
Meets AMS-DTL-23053/5, compatibility: UL224
Color code soundness: SAE-AS 81531 and MIL-STD-202F/215J
Dimension(2: 1)
