Calcium Silicon Board Production Line

Calcium silicon board production line

Basic technical data
1. Product name: Non-asbestos fiber cement board
2. Standard: In conformity with National Building Material Industry Standard JC/T 412.1-2006. < Non-asbestos fiber cement board>
3. Raw material: Cement, reinforced fiber, coal ash additives
4. Product specification: ( L*W*T) 2440× 1220× 6-30mm
5. Capacity: 3 million -5million /year( calculate by 2440× 1220× 6mm board, 24 working hours continous production )
6. Production organization arrangement: 1) 3 shifts per day, 8 hours per shift, 300working days per year 2)total wokers need for this line is 52 staff, including 2 management staff, 2 techincal staff and 48 workers.

No. Test items Standard indicators Test results
1 Bending degrees
Horizontal > =22Mpa 24.9Mpa Qualified
Vertical > =17 Mpa 21.4Mpa
2 Impact strength > =2.0 KJ/m2 3.7KJ/m2 Qualified
3 Indensity > =1.6g/cm3 1.72g/cm3 Qualified
4 Water absorption < =24% 16.8% Qualified
5 Waterproofness According to the National standard GB8041 tested -24H checking allow damp mark on the back of the board, but no water drop Meet the National standard GB8041 Qualified
6 Freezing resistance According to the National standard GB8041 tested- after 25 times Cycliccrackingno break and layer appear Meet the National standard GB804

1 Qualified
7 Sound resistance Meet 4sdb (GBJ75-B4)
8 Radioactivity Meet standard GB6566-2001A)
9 Noninflammability In accordance with the GB5464-85 and GB8624-88, A class building materials
