Automatic PE Film Bottle Shrink Packing Machine

Automatic PE film bottle shrink packing machine
The automatic film packing machine is the new type wrapper developed by jst company according to domestic and abroad similar machines' advantage. It applies widely for combination packing such as beverage, food, medicine and chemical products, etc. It does not adopt salver and does not need box. It can pack perfectly no matter square, round or ellipse bottle. Ocular effect is good and packing cost is low. The machine adopts novel optimizing design and PLC autocontrol, Man-machine conversation track. And orientation is exact. The following pack entering state stops bottle lack, bottle collapse, which has advantage of agile adjustment and beautiful appearance. Adjustable heat wind recycling structure applies all heat shrink wrapping (include color printing). Film changing is easy and fast. It has malfunction alarm and complete lock-stopping function and running is reliable, which gives firm assurance for constant quality and long time continuous prodction.
The PE film bottle shrink packing machine is made of high quality steel and stainless steel, which has advantage of compact structure, long life-span and low energy consumption. The new type full automatic PE film wrapping machine with patent is the preferred matching equipment for beverage bottle filling line.
Technical Parameter of automatic bottle packing machine
L Electrical source: AC 380V/220V 50HZ
L Maximum power: 18KW
L Working air pressure: 0.6 MPa
L Air compressor requirement: Exhaust pressure: 0.8MPa, flux: 0.25m3/min
L All kinds of thermal shrinkage film for example: PE, PP, PVC, POF
L Width of wrapping film: ≤ 600mm
L Thickness of wrapping film: 0.03-0.15mm
L Feeding conveyor height: 920mm(adjustable)
L Length of feeding conveyor: 2600mm
L Outlook dimension of equipment: 5500*3200*2100 mm
L Total Weight of equipment: 1200kg
Speed: 0-14 groups/minute
FAQ for packing machines
1. What kind of products will you produce?
2. What is the capacity(per hour) you want?
3. What kind of package, plastic bottle, glass bottle: Volume, height, neck diameter, diameter of bottle or other please inform us of details.
4. Sole machine or whole production line?
