Product Description

Full automatic PE film bottle shrink wrapping machine

The automatic film wrapping machine is the new type wrapper developed by our company according to domestic and abroad similar machines' advantage. It applies widely for combination packing such as beverage, food, medicine and chemical products, etc. It does not adopt salver and does not need box. It can pack perfectly no matter square, round or ellipse bottle. Ocular effect is good and packing cost is low. The machine adopts novel optimizing design and PLC autocontrol, Man-machine conversation track. And orientation is exact. The following pack entering state stops bottle lack, bottle collapse, which has advantage of agile adjustment and beautiful appearance. Adjustable heat wind recycling structure applies all heat shrink wrapping (include color printing). Film changing is easy and fast. It has malfunction alarm and complete lock-stopping function and running is reliable, which gives firm assurance for constant quality and long time continuous prodction.
The bottle wrapping machine is made of high quality steel and stainless steel, which has advantage of compact structure, long life-span and low energy consumption. The new type full automatic PE film wrapping machine with patent is the preferred matching equipment for beverage bottle filling line.

Technical Parameter of automatic bottle wrapping machine
l Electrical source: AC 380V/220V 50HZ
l Maximum power: 18KW
l Working air pressure:0.6 MPa
l Air compressor requirement: exhaust pressure: 0.8MPa, flux: 0.25m3/min
l All kinds of thermal shrinkage film for example: PE,PP,PVC,POF
l Width of wrapping film:≤600mm
l Thickness of wrapping film: 0.03-0.15mm
l Feeding conveyor height: 920mm(adjustable)
l Length of feeding conveyor:2600mm
l Outlook dimension of equipment: 5500*3200*2100 mm
l Total Weight of equipment: 1200kg
Speed: 0-14 groups/minute

PE film shrink wrapping machine drawing :
