Hot Tea Bottles Tumbling Sterilizer Machine (DP-8)

Hot tea bottles tumbling sterilizer machine (DP-8)

1. Hot tea bottles tumbling sterilizer machine is mainly used after hot filling fruit juice and tea in PET bottle to sterilize PET bottle mouth and inside surface of caps, which haven't been disinfected by high temperature.
2. It mainly consists of chief conveying chain system, surport, bottle reversing chain system, bottle reversing guiding rod and bottle repositioning rod.
3. It uses inner thermal medium to disinfect bottle mouth and caps without any other heat source, so it can save energy.
4. The machine is fully made of SUS304 stainless steel, elegant in appearance more convient in operation

Hot tea bottles tumbling sterilizer machine is mainly used in sterilizing PET bottle mouth and inside surface of caps.
In which haven't been disinfected by the tea, Furit juice which having been filled in PET bottle. It mainly consist of chief conveying chain system, support, bottle reversing chain system, bottle reversing guiding rod and bottle reposition rod, Use its inter thermal medium to disinfect bottle mouth and caps without any other heat souce, So it can save energy. The machine from JST company is fully made of SUS 304 stainless steel, more convenient in operation. This series model machine capacity can be from 1000 bottle per hour to 12000 bottle per hour.

Hot tea bottles tumbling sterilizer machine specifications:
1) Usage: Sterilizes the mouth of low temperature material bottles after the hot filling process is completed a) After filling and capping, bottles will be automatically inverted 90° , then placed flat by the machine b) Then the interior of the caps will be sterilized by high-temperature material c) At last the bottles will be placed vertically to be cooled by a spray-cooler
2) Imported transmission chains can be adjusted infinitely, helping the machine run steadily and reliably without harming the bottles

Tea bottles inverse sterilizer machine after sales service:
We will send one professional engineer to install the whole line for you, but you should pay him USD 60 / DAY as salary, also include his return tickets, room, food and visa fee.
Machine guarantee time: 12 months

FAQ for machines
1. What kind of products will you produce?
2. What is the capacity(per hour) you want?
3. What kind of package, plastic bottle, glass bottle: Volume, height, neck diameter, diameter of bottle or other please inform us of details.
4. Sole machine or whole production line?
