Complete Plastic Bottle Unscrambling Machine / Unscramble Bottle Machine

Complete Plastic Bottle Unscrambling Machine / Unscramble Bottle Machine
This plastic bottle unscrambling machine is used before bottle washing filling capping machine.
Features of unscamble bottle machine:
1. PLC control, full-automatic working from jst machinery.
2. Torque limit part is designed for the main motor reducer so as to protect the machinery if malfunctions occur.
3. Two put-casts in one cycle ensure that every work location should be with one bottle, which enhances bottle output efficiency.
4. The bottles are neck locked through the air conveyor so as to avoid Overturn in delivery.
5. Dilapidated bottles will be eliminated by a special device.
6. A lock detector is equipped for alarming; When locked, the machine will Automatically stop.
7. A photoelectric switch is set for starting when there is no bottle and stopping when there are bottles.
8. An oil pump will readily fill up the gears, bearings and the cams
9. Maintenance doors and mould replacement door provided.
10. Machine outer tank and revolving tank and meet the bottle part are all Stainless steel AISI304. Frame part adopts high-grade carbon jointing.
Automatic bottle unscrambler for PET bottle
Model: LP-14
Working location: 14PCS
Capacity: 8000b/h
Maximum capacity: 10000b/h
Air supply pressure: 0.7Mpa
Air consumption: 1.5m3/min
Suitable bottle: Diameter-50-96mm, height 165--310mm
Main motor power: 1.5kw
Bottle elevator power: 0.75kw
Brand: Jst machinery
Dimension: Φ 1660X2060mm
Machine weight: 2000Kg
Automatic plastic bottle unscrambling machine after-sales service:
We will send one professional engineer to install the whole line for you, but you should pay him USD 60 / DAY as salary, also include his return tickets, room, food and visa fee.
Machine guarantee time: 12 months
FAQ for complete bottle unscrable machine:
1. What kind of products will you produce?
2. What is the capacity(per hour) you want?
3. What kind of package, plastic bottle, glass bottle: Volume, height, neck diameter, diameter of bottle or other please inform us of details.
4. Sole machine or whole production line?
