Soya Sauce Filling

General descriptionBottles are transported to rinser by bottle-in screw and starwheel. The special gripping claw of the rinser grips the bottle neck to overturn the bottle, inner wall of which is washed with rinsing water by special spray nozzle. After rinsing, dripping and drying, the bottle is transported to filler through starwheel and is positioned on the bottle holder of the elevation cylinder, under effect of which, the bottle rises to mesh with filling valve and simultaneously open the filling valve to start filling. While the level achieves the height of air back tube, the filling stops and whereafter the vacummizing channel start to take out the foam and modify the level. After the bottle falls, the filled bottle is transported to capper through tranisition starwheel. At this moment, the capping head has already held one cap. Under effect of cam guide track, the cap pressing plunger descends toward the bottle on the down platform and then to do capping operation by thrust ring. After capping ends, the capping head rises and the finished bottle is transported through starwheel to bottle-out conveyor and sent out of the monobloc to go to next procedure. Main featuresJBXGF series rinsing/filling/capping monobloc can be used for glass bottled vinegar and soy sauce. It adopts high-efficiency spray nozzles. The rinsing water sprays with set angle that can wash any part of the bottle's inner wall. The rinsing is complete and rinsing water is saved. Adopt endurable, long life and free lubrication structure design, reducing the equipment running cost. Adopt bottle bottom holding transport and nylon guard ring. Bottle-in and bottle-out has pre-cover function to ensure stable running of bottles. Rinser, filling valves and capping heads can be elevated to adapt to different height bottles in design scope. All parts touching with product adopts 316L stainless steel, no dead corner, easy to clean and durable. Negative-pressure gravimetric filling with CIP function. High automation, easy and friendly operation interface with strong expansibility; Electric components adopts famous brand.
