Automatic Drinking Pure &Mineral Water Filling Machinery (CGF)

Automatic Drinking Pure &Mineral Water Filling Machinery

1. Low price with high quality
2. Capacity: 2000-22000bph
3. Pet bottle

Automatic Drinking Pure &Mineral Water Filling Machinery

Automatic Water Filling Machinery-----Characteristics:
1. Air conveyor connected with thumbwheel directly instead of screw and conveyor chains, which is easy to bottle change, it's just replace star-wheel, inlet bottle screw and arc guide plate.
2. There is no need to adjust the height of equipments through neck holding tech for bottle transmission. It is simply to replace the bottle diameter related arc guide board, thumbwheel and nylon fittings etc.
3. The automatic water filling machinery specially designed bottle clip is made of stainless steel and durable, non-contact bottle-screw part, to avoid secondary contamination, no process dead angle, which is easy to clean.
4. Automatic Water Filling Machinery Parts which contact with the liquid are all of high quality stainless steel or food-level engineer plastics, and achieve the national food sanitary standard.
5. High speed and large-traffic gravity filling valve, exact liquid level, it can ensure accurate filling technology requirements.
6. The head of capping device adopts constant torque magnetic device to guarantee cap quality and bottle cap.
7. The automtaic grade of water filling machine adopts high effective cap sorting system and completely self control and protective devices.
8. The whole water filling machine machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
9. Advanced control system with the functions of production rate control, lack of cover detection, blocked bottle stop and output statistics, etc.
10. Photoelectric detection of various components and a high degree of automation, it is easy to operate.
11. The machine adopts advanced(programmable logic controller) PLC control machinery and automatic operation, the main electrical apparatus elements and pneumatic components are all introduced from world famous brand products such as: Siemens, MITSUBISH, ABB, etc.
12. The whole operation controlled by the advanced touch-screen, the controller can be easily

Automatic Drinking Pure &Mineral Water Filling Machinery

Automatic Water Filling Machinery-----Washing Part


The bottle is blew into the bottle shifting wheel, when the flushing clamp reaches the bottle neck, the jaw will clamp the bottleneck, under the guidance of the rail, the clamp will turn the bottle 180° Into an upright position, through second bottle pusher into the filling position.

Automatic Water Filling Machinery-----Filling Part


The filling part is manly composed of a filling valve and filling transmission parts. The washed bottle reaches the filling position via the bottle shifting wheel. In the mean time, the bottle clamping plate of the filling machine will clamp the bottle and move up to seal the bottle, filling valve will open, send the liquid into the bottle. When the liquid level of the bottle reaches the trachea of the filling valve, the filling will stop.

Automatic Water Filling Machinery-----Capping Part


The capping part consists of screw heads, capping transmission part, a sorting part and an under cover tube parts. The bottle which has finished filling will enter the capping position via the driving wheel. The photoelectric detection of the detecting signal detects the bottle, send a message to the valve cover, the cylinder cap will open, the caps will be blew into the cover plate by compressed air.
