Automatic 3 in 1 Drink Water Bottling Machine/Filling Equipment

Automatic 3 in 1 Drink Water Bottling Machine/Filling Equipment
1. Mineral water&pure water filling plant
2.3 in 1 monoblock
3. PET bottled filling
4. PLC

Automatic 3 In 1 Mineral Water Plant/Filling Machine

Descriptions-----Drink Water Bottling Machine
(1)Washing, filling, capping three in one equipment.
(2) The suspending bottle-neck clamping design make the bottle be stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production and different types of bottles easily.
(3) The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle's screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle. The special filling valve makes the filling speed fast and the filling liquid level control correct
(4) Magnetic torque is used for screw capping, and the power of screw capping can be adjusted. Capping is reliable and do no harm to the caps.
(5) Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this machine. The advanced gravity filling technology used in this machine makes the filling quick, steady and accurate.

Automatic 3 in 1 Drink Water Bottling Machine/Filling Equipment

Characteristics------Drink Water Bottling Machine
1. Using the wind sent access and move wheel in the bottle directly connected technology; Canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough...
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneider, OMRON.

Automatic 3 in 1 Drink Water Bottling Machine/Filling Equipment

Drink Water Bottling Machine----Washer
The bottle is blew into the bottle shifting wheel, when the flushing clamp reaches the bottle neck, the jaw will clamp the bottleneck, under the guidance of the rail, the clamp will turn the bottle 180° Into an upright position, through second bottle pusher into the filling position.

Drink Water Bottling Machine----Filler
The filling part is manly composed of a filling valve and filling transmission parts. The washed bottle reaches the filling position via the bottle shifting wheel. In the mean time, the bottle clamping plate of the filling machine will clamp the bottle and move up to seal the bottle, filling valve will open, send the liquid into the bottle.

Drink Water Bottling Machine---Capper
The capping part consists of screw heads, capping transmission part, a sorting part and an under cover tube parts. The bottle which has finished filling will enter the capping position via the driving wheel. The photoelectric detection of the detecting signal detects the bottle.

Automatic 3 in 1 Drink Water Bottling Machine/Filling Equipment

Reliable Machinery----Service
Your inquiry related to our product & price will be replied within 24hours
Well-trained & experienced staff are to answer all your inquiries in English and Chinese
Working time: 8: 30am ~6: 00pm, Monday to Friday(UTC+8).
OEM & ODM projects are both available
Your business relationship with us will be confidential to any third party.
Good after-sale service offered, please get back to us if you got any questions.
