High Quality Automatic 5 Gallon Barreled Water Bottling Machine/Production Line (QGF)

Get Latest Price

Payment Type:: L/C, T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangu Province, Zhangjiagang
Payment Type:	L/C, T/T

Product Description

High Quality Automatic 5 Gallon Barreled Water Bottling Machine/Production Line
Description:
This 3gallons 5gallon automatic bottle/jar/bucket/barreled filling machine line is for filling mineral water, distilled water and purified water into barreled/bucket/jar. The machine works reliably and efficiently based on the compact structure and high automatic technology. It is the fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.

Ø The spray nozzle for washing is the technology products of American sprayer company
Ø Intellectual management, controlled by MITSUBISHI micro-computer.
Ø Siemens electrical element
Ø AIRTAC pneumatic element
Ø The whole set of equipment is made of stainless steel especially for food
Ø Including system for automatic cap settling and cap transportation
Ø Installment of automatic trouble protected device

High Quality Automatic 5 Gallon Barreled Water Bottling Machine/Production Line
QGF series 5 gallon filling machine is designed for producing 5 gallon barrel drinking water. There are 8 kinds of machines which can produce 60, 100, 150, 300, 450, 900, 1200 and 2000 5 gallon barrel drinking water per hour. Every machine consists of rinser, filler and capper. The rinser has several sprays which can be used as for both clean water rinsing and disinfectant rinsing. The disinfectant can be recycled. The machine also has automatic capping device, and cap rinsing device. The whole production line can automatic feeding barrel, rinsing, sterilizing, filling, capping, counting and output.

High Quality Automatic 5 Gallon Barreled Water Bottling Machine/Production Line
What service Reliable Machinery Co., Ltd can offer you?
Your inquiry related to our product & price will be replied within 24hours
Well-trained & experienced staff are to answer all your inquiries in English and Chinese
Working time: 8: 30am ~6: 00pm, Monday to Friday(UTC+8).
OEM & ODM projects are both available
Your business relationship with us will be confidential to any third party.
Good after-sale service offered, please get back to us if you got any questions.
Weclome to visit our company!

Model	QGF-100	QGF-200	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200
Filling heads	1	2	3	4	8	8	8
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	270×490	270×490	270×490	270×490	270×490	270×490	270×490
Capacity(b/n)	100	200	300	450	600	900	1200
Gas pressure(mpa)	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
Gas consumption(m3/min)	0.37	0.37	0.6	0.8	1	1.5	1.8
Moto power(kw)	1.38	1.75	3.8	3.8	7.5	9.75	13.5
Rated voltage(v)	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
Weight(kg)	680	800	1500	2100	3000	3500	4500
