Automatic 5 Gallon Drinking Bottling Water Filling Machine/ Apparatus/ Device (QGF)

Get Latest Price

Payment Type:: L/C, T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Zhangjiagang City, Jiangsu Province
Payment Type:	L/C, T/T, Western Union

Product Description

Automatic 5 Gallon Drinking Bottling Water Filling Machine/Apparatus/Device/Equipment/Facilities (QGF)

1. Product: 5gallon water
2. CE&ISO certificate
3. Bottle: 18.9L

Automatic 5 Gallon Drinking Bottling Water Filling Machine/Apparatus/Device/Equipment/Facilities (QGF)

This automatic 5 gallon bottling machine specially produces 5 gallons bottled drinking water. This automatic 5 gallon bottling machine integrates bottle washer, filler and sealer into one unit, in order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching are used in bottle washer. Washing solution can be used circularly. The sealer can seal bottle caps automatically. This automatic 5 gallon bottling machine equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy, also this automatic 5 gallon bottling machine can automatically carry out bottle feeding washing, sterilizing, filling capping, counting and products discharging. This automatic 5 gallon bottling machine is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.

Automatic 5 Gallon Drinking Bottling Water Filling Machine/Apparatus/Device/Equipment/Facilities (QGF)

How to get your suitable machine or production line?
Find our products through Reliable Machinery Co., Ltd in Google, Baidu. Bing, Alibaba. COM etc
Enquiry: Contact us by email, phone call, fax, Instant Messenger and let us know your enquiry.
Discussion: Specify the items you desire, confirm specification; OEM/ODM consultation.

1. What kind of products will you produce?
2. What is the capacity(per hour) you want?
3. What kind of package, plastic bottle, glass bottle: Volume, height, neck diameter, diameter of bottle or other please inform us of details.
4. Sole machine or whole production line?

Quotation: Prices offered and accepted.
Place order as per contract or discussion.
Perform invoice( sales contract ) In duplicate confirmed and kept by both sides.
Payment settled.
Order completed under our arrangement.
Goods shipped as per contracted term.
Goods arrive at local port or warehouse, depending on contracted term.
Support & re-ordering.

Model	QGF-100	QGF-240	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200
Filling heads	1	2	2	3	4	6	12
Volume(Gallon)	3& 5	3& 5	3& 5	3& 5	3& 5	3& 5	3& 5
Barrel size(mm)	270*490	270*490	270*490	270*490	270*490	270*490	270*490
Capacity(b/h)	60-100	100-240	250-300	400-450	600-800	800-900	1000-1200
Gas pressure(Mpa)	0.4-0.6	0.4-0.6	0.4-0.6	0.4-0.6	0.6	0.6	0.6
Gas consumption(m³ /min)	0.37	0.37	0.6	0.8	1	1.5	1.8
Motor power(kw)	1.38	1.75	3.8	3.8	7.5	9.75	13.5
Related Voltage(V)	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ	380V/HZ
Weight(kg)	680	800	1500	2100	3000	3500	4500
