AG-Iir002c Medical Supplier Hospital Radiant Warmer for New Born

Specification

 1. Microprocessor based servo controlled

2.Control mode :Air & Baby temperature,Humidity

3.Two skin probes for the measurement of central and peripheral temperature.

4.Baby weight,X-ray cassette,humidity control system.

5. Air temperature, skin temperature, humidity, timer and heat power separately displayed by LED

6. Alarms functions: Power failure; Over temperature; Temperature deviation; Temperature sensor failure; Fan failure;

7. Silence/reset button for alarms

8. >37 °Ctemperature setting, A keypad lock prevent inadvertent changes the setting

9. Trough for pulling and pushing, which is convenient to add water and wash

10. Fan with low noise and long life-span

11. Temperature deviation and over temperature could be amended in front panel directly

12. A second thermal cut-off function for more safety

13. Skin temperature sensor failure protect function avoid over temperature

14. The infant bed inclination angle is adjustable

15. Six operating windows, two sides operating windows can be swiveled

16. Heater is electrically cut-out if air temperature inside incubator exceed 40 °C

17. Cabinet with three drawers, silence castors

18. Large size and double wall hood

Standard configuration

Main body(including the double transparent hood, control system, infant bed, water trough), two skin temperature sensor, I.V.pole,tray ,mattress, baby scale,drawers, slience luxurious castors


Technical data:

1  Power Supply: ~ 220V, 50/60Hz

2  Power consumption:  650W

3  Operation environment conditions:

- An ambient Temperature:  20°C~ 30°C

-  An ambient Humidity:  30% RH ~ 75% RH

-  An ambient air pressure:  700 hPa ~1060 hPa
  -  An ambient air velocity less the 0.3m/s

4  Control temperature range:

 -  Air temperature : 25°C~37°C, 37.1°C~38°C

 -  Skin temperature : 32°C~37°C, 37.1°C~38.5°C

5  The warm-up time : 45 minutes

6  The function of alarm :

6.1 The over temp of air temp :  38°C    (Heater is cut-out simultaneously, the thermal cut-out should be reset by manual)

6.2 The second thermal cut-out temperature:  40°C     (Heater is cut-out simultaneously, the thermal cut-out should be reset by manual)

6.3 The alarm for deviation:

 -  Air temp: ±3.0°C                   (Heater is disconnected simultaneously at +3°C)

 -  Skin temp : ±1.0°C               (Heater is disconnected simultaneously at +1°C)

6.4 Alarm for Sensors:

When the skin (or air) temperature sensor is shut off or short circuit,cut off the heater,give out alarm with sound and light .

6.5 Alarm for power failure

The power fails,give out alarm with sound and light.

6.6 Alarm for fan failure

The fan stops working or appear fault, give out alarm with sound and light and cut off the heater power.

6.7 Low water level

When the water level in trough is lower than rated level, low water level caution light is on.

7  Control humidity range:   30%~90%RH

8  Weighing scale

8.1 Weight range: 0.2~10Kg

8.2 Resolution: 1g

9 Transport and storage

Environment temperature: -10°C~+40°C

Relative humidity ≤80%RH

Atmospheric pressure range: 500hPa~1060hpa

10 Carbon dioxide (CO2) level within the constant temperature cover: less than 0.4%  when a 4% mixture of  CO2  in air is delivered at 750ml/min at a point 10 CM above the centre of the mattress through an 8 mm diameter tuber in vertical direction from the mattress to top.

11. Infant bed tilt angle: +-10degree

12.Mattress size: 67cm(L)X 54cm(W)

13. Trough capacity: 1200ml

14. Air filter: 0.5um

15.Baby scale range:10g-7kgs

Transport and storage

Environment Temp: -10--+70°C

Environment Relative Humidity: ≤ 80%RH

Atmospheric Pressure: 500~1060Hpa
