Me-Series PP Film Recycling Line

ME-Series PP Film Recycling LineIntroductionΔ Application: Used for waste plastic crushing washing dryingΔ Process material: Baled or loose PP/PE film/bag/woven bagΔ Finished product size: 30-40mmΔ Moisture content remain: Less than 3%We can customize the washing line according to client's requirement. Production Process1. Size Reduction — 2. Friction Washing — 3. Washing & Density Separation — 4. Moisture Removal — 5. Product CollectingTechnical DataModel: ME-500Δ Capacity: >500 kg per hourΔ Installed power: 179.5kwΔ Hot washing: OptionalΔ Water supply: 3-5 ton per hourΔ Manpower: 3 personΔ Estimated line size: 29m*2.5m*4mMain Machines & FunctionPlastic Crusher (Wet Type)Δ Used for size reduction of the material into flakesΔ Special V-shape rotor design for film/bag crushingΔ Screen size: 100mm*20mm (length*width)Δ Output size: 30-40mm; Capacity>500kg/hr (for film/bag/woven bag crushing)Friction WasherΔ Used to scrubbing flakes by high speed blades to remove dirt and waterΔ Rotary speed: 800rpm for high efficiencySink-Float TankΔ Used to separating the sinkable contamination and cleaning the PP/PE flakes by rolling drumsΔ Sink-float tank designed with 5PCS automatic drums on top for flakes automatic cleaning and conveyingΔ The side dirt lift screw conveyor is optionalDewatering MachineΔ Used for removal of the moisture from the flakes by high speed bladesΔ Rotary speed: 1500rpm for high efficiencyΔ Moisture content remain: 5-8%Hot Air Drying SystemΔ Used for reducing moisture content from flakes by hot airΔ Moisture content remain: <3%Optional MachineHot Washing TankΔ Used to washing the flakes by hot water to remove glue and greasy dirtΔ Feeding caustic soda/detergent to washΔ Heating by electricity or customizedΔ Tank outside with heating protecting layer made of rockwoolΔ Special design for PP/PE recycling
