Galvanized Steel Suspension System (S- ceiling grid)

Galvanized Steel Suspension System (S- ceiling grid):

Suspension system has many advantages, include: Beauty, good strength, cauterization resistance, and rust resistance.

Specifications:
1) Main tee:
A) 3600(3660)X38X24mm
B) 3600(3660)X32X24mm
C) 3600(3660)X26X24mm

2) Long Cross tee:
A) 1200(1220)X26X24mm
B) 1200(1220)X24X24mm
C) 1200(1220)X38X24mm
D) 1200(1220)X32X24mm

3) Short cross tee:
A) 600(610)X26X24mm
B) 600(610)X24X24mm
C) 600(610)X38X24mm
D) 600X(610)32X24mm

4) Wall angle:
3000(3050)X22X20mm
3000(3050)X22X22mm
3000(3050)X21X21mm
3000(3050)X24X24mm

5) Thickness: 0.2- 0.50mm

6) Other size and thickness are also available.Groove t bar also are available.

Advantage:
1. Convenience in installation, it shortens working time and labor fees.
2. Neither air nor environment pollution while installing. With good effect for space dividing and beautifying.
3. Using fire proof material to assure living safety.
4. Can be installed according to practical demands.
5. The physical coefficient of all kinds Suspension Ceiling T bar are ready for customer and designers' reference and request.

Install:
1. The Suspension Ceiling T bar is the light style. It is hung according to strict requirements. Then put the sound absorption board on the Ceiling T bar.
2. Hang the Ceiling T bar with H light steel channel. Insert the board into the Ceiling T bar.
3. Set the PVC plasterboard on the Suspension Ceiling T bar. There are 15 plaster points which will be put with the lines and set with nails.
