SRL-W800/2000 Horizontal Heating and Cooling Mixing Machine Unit

Heating Mixer:
Motor power of heating mixer: 110KW;
Inverter: 132KW ABB;
Volume of heating mixer: 800L;
Material of vessel: Stainless steel (6mm);
Quantity of paddle: 3 pieces;
Paddle speed: 0~740rpm;
Discharge method: Automatically;
Discharging cylinder: Φ 100mm*300mm;
Cover cylinder: Φ 100mm*65mm;
Heating method: Self-friction;

Cooling Mixer:
Motor power of cooling mixer: 22KW;
Volume of cooling mixer: 2000L;
Material of vessel: Stainless steel (6mm);
Discharge method: Automatically;

More models as follows:

Item No.	SRL-W300/1000	SRL-W500/1500	SRL-W800/2500	SRL-W1000/3000	SRL-W800*2/4000
Total Volume(L)	300/1000	500/1500	800/2500	1000/3000	800*2/4000
Effective Volume(L)	225/700	330/1000	600/1500	700/1200	1200/2700
Blade Speed (rpm)	475/950/80	430/860/70	370/740/60	300/600/50	350/700/65
Heating/Cooling Way	electric self-friction/water
Mixing Time(min.)	8-12	8-15	8-15	8-15	8-15
Motor Power(KW)	40/55/705	55/75/15	83/110/22	110/160/30	83/110*2/30
Weight(kg)	3300	4200	5500	6500	8000
