Conical Twin Screw Extruder (SJSZ80/156)

Get Latest Price

Payment Type:: T/T, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Zhangjiagang, China
Payment Type:	T/T, Western Union

Product Description

SJSZ80/156 Conical Double Screw Extruder

Diameter of Screw: 80/156mm;
REV Speed of Screws(r/m): 1-35;
Effective length of screws(mm): 1800;
Main Motor Power: 55KW;
Barrel heating power: 36KW;
Screw feeding power: 1.1kw;
Fan cooling power (for barrel): 0.37KW*3sets;
Vacuum power: 2.2KW;
Granulator power: 1.5KW, 3 knives;
Converter: ABB;
Barrel and screw are made of nitride steel(38CrMoAlA);
Barrel cooling via independent low noise fans;
5 barrel heater zones;
Barrel heater: Cast aluminum heater;
Temperature Control: Be controlled by OMRON PID temperature controller;
Granulator method: Hot-cutting;
Including a mould head and cutters;
Low-voltage electric elements: Siemens/SCHNEIDER;
With a control cabinet;

Dimension: 4750mm*1550mm*2460mm
Weight: 6500KG
