Product Description

SJSZ Series Conical Double/Twin Screw Plastic Extruder/Extrusion/Extruding Machine

Product Description:
This double/twin screw extruder/extrusion/extruding machine could be used to produce PVC pipes, PVC profiles, PVC sheet, PVC film, etc.
This double/twin screw extruder/extrusion/extruding machine is also suitable for making PVC pellets/granules.

Main Technical Parameters:

Model No.	SJSZ45	SJSZ51	SJSZ55	SJSZ65	SJSZ80	SJSZ92
Screw Diameter (mm)	45/100	51/105	55/120	65/132	80/156	92/188
Qty. of Screw	2
REV Direction of Screw	Turning outwards with different direction
Screw Speed (rpm)	1-38	1-38	1-38	1-36	1-35	1-34
Screw Effective Length (mm)	1000	1050	1150	1430	1800	2520
Main Motor Power(KW)	15	18.5	22	37	55	90
Barrel Heating Power(KW)	12	15	18	24	36	48
Capacity(kg/h)	95	110	150	250	380	520
Center Height of Machine (mm)	1000
Net Weight(kg)	3000	3200	4200	5000	6500	7500
