HDPE Bottles Blow Molding Machinery 1~5L
ABLB65II
This type of machine is suitable to produce different shapes of plastic bottles from 500ml to 4L.
Adopt Mitsubishi PLC from Japan
Contactor use Schneider from France
Most of spareparts of hydraulic system and pneumatic system are imported from Japan, Korea, France and Taiwan, China to ensure the quality of the machine.

Max. Product volume	4 liters
Dry cycle	800X2pc/h
Screw diameter	65mm
Screw L/D ratio	24 L/D
Screw drive power	18.5 KW
Screw heating capacity	5.7 KW
No.of heating zone	3 zones
Output of HDPE	80 KG/H
Oil pump drive power	7.5 KW
Clamping force	45 KN
Max.size of mold	148-508mm
Mold stroke	320X360mm
Max.die diameter	140mm
Blow pressure	0.6mpa
Air volume	0.7 M³/MIN
Cooling water pressure	0.3mpa
Water consumption	65 L/MIN

The main components of the machine. ( ABLB65II )

electronic parts
Name	Trader
Micro computer control system	Japanese MITSUBISHI
Temperature Controller	HuiBang PID
Auxiliary Relay	OMRON
contactor	Schneider from France
Electric motor	Three phase 220V or 380V
Power Source	TAIWAN MEANWELL
Transducer	TAIDA FROM CHINA
hydraulic parts
Name	Trader
Oil pump	TAIWAN HIGH-TECH
Valve	TAIWAN JINSHUN
Oil pump and connection	TAIWAN JINSHUN
Sealed part	HALLITE
air control system
Name	Trader
Cylinder	AIRTAC
Air Valve	JELPC
