2012 New Type Pet Packing Strap Extrusion Line

New type high output PET PP strapping band extrusionn line with low power consumption

Overview:

The series PET PP strapping band extrusion line is new equipment designed by HorseRider. By combining the characters of the same type of machines in domestic and overseas markets, the production line is of the most advanced technology in this field. It is of characters of high efficiency, high output, low power consumption and energy saving.

Features of PET PP strapping band extrusion line

1. Using the recycling bottle slices as raw materials by making them melt directly,
Which reduces the course of raw material-making

2. With the multi-purpose machine, it can produce PET straps in different specifications
Directly and doesn"t need to change the mould head

3. The products has the same transparency as made from new polyester slices, but
The tensile strength and shock resistance are stronger

4. Low energy consumption, high production capability

5. Easy to operate, saves manpower

Characters of PET straps

PET Straps have advantages as good stiffness, high temperature resistance. The specific gravity is as 1/5 as steel. The straps can be used for packing in various areas. The characters of such straps are as follows: High tensile strength, small percentage elongation, resistance to impact, not easy to be broken and good softness.

Model number	HRPS
Main motor	30-90KW
Motor drive	AC
Power supply	380V 50HZ or customized
Strap width	9-25mm
Strap thickness	0.5-1.5mm
Drying volume	100kg/h
Loading power	3KW
Daily output	1000-2000 kg/day
Worker	2-3
Workshop size(L*W*H)	25000*5000*6000mm
