Product Description

CNC Sinker EDM [ [EDMN2180CNC ]
AC Servo: Japan YASKAWA or Panasonic
Linear guideway: Taiwan HIWIN
Denmark Grundfos Pump
Current: 90A
Smooth: Ra< =0.4um
Precision: < =0.005mm.

Parameters		UNIT	EDMN2180CNC
Working Tank (LxWxH)		mm	3200 x 1650 x 740
Max. Oil Level		mm	550
Table Size (LxW)		mm	2500 x 1200
Travel Size	X-One Spindle	mm	2100
	X-Twin Spindle	mm	1400
	Y	mm	800
	Spindle Travel (Z)	mm	600
Distance between Spindle Nose to Work Table	Min.	mm	600
Distance between Spindle Nose to Work Table	Max.	mm	1200
Max. Table Load (Workpiece weight)		mm	7000
Max. Spindle Hold (Electrode weight)		kg	300
Oil Tank		L	2500*2
Oil Tank Dimension (LxWxH)		mm	3840 x 2600 x 700
Control Method			AC / DC (Japan SANYO)
Rated Current		A	150 / 200
Machine Dimension (LxWxH)		mm	3800 x 4050 x 4050
Machine Weight		kg	One Spindle:15000 Twin Spindle:18000
