Chinafor EPS Pelletizing Production Line

ChinaFor EPS Pelletizing Production Line
Using the latest technologies from Europe, US and Japan to complement our 35 years of experience in equipment manufacturing, we have designed many kinds of washing machines to satisfy the needs to effectively clean and crush PET bottles.

We combine the latest domestic technology of steam washing systems with imported PLC Logic Control systems and electrical parts to satisfy our customers' requirements.

EPS pelletizing production line Configuration:
No. Equipment NameTotal PowerQuantityComments
1 Bale opener15-18.7kw1 set
2 Belt Conveyor1.1-3kw1 set
3 Roller screening machine4-7.5kw1 set
4 Belt Conveyor1.1-3kw1 set
5 Label remover machine20.5-29.5kw1 set
6 Belt Conveyor1.1-3kw1 set
7 Belt conveyor for sorting2.2-5.5kw1 set
8 Belt conveyor1.1-3kw1-2 set
9 Crusher30-160kw1-2 set
10 Screw feeder2.2-4kw1 setTo see whether the actual
11 Screw feeder2.2-5.5kw1 set
12 Washing tank12.3-14.5kw1 set
13 Screw feeder2.2-5.5kw1 set
14 Steam Washer7.5-26.8kw1 set
15 Screw feeder2.2-5.5kw1 set
16 Friction washing machine22.75-90.5kw1-2 set
17 Washing tank12.3-14.5kw1 set
18 Screw feeder2.2-5.5kw1 set
19 Horizontal Dewatering Machine22.75-90.5kw2 set
20 Cyclone separator0.5-11 setTo see whether the actual
21 Drying system40-70kw1 set
22 Label separator machine3.7-5.5kw1 set
23 Air transportation system5.5-15kw1 set
24 Storage silo1-2m31 set
25 Control System1, ABB Brand Convetor
26Using Omron temperature controller, Siemens contactor1 set
