Long Shank Carbide Square End Mills(D3~D20mm*4Flutes)
1. Specification
(1) D3~D20mm.
(2) Super TiAlN coated
(3) 4 flute
(4) Micro Grain 0.5-0.6um
(5) Be made of Tungsten steel/ solid carbide.
(6) Different Grade with M SERIES(HRC45) & H SERIES(HRC55) & S SERIES(HRC62)
2. Application
* Suitable for machine tool steel, alloy steel, mold steel, carbon steel, cast steel and other highly hardened materials.
3. Advantage
(1) Be made by 5-AXIS tools grinding machine, guarantee the quality and precision first
(2) Each end mill is inspected by Zoller Machine
(3) OEM is available
(4) Can be customized per as your request
(5) Free samples for test
(6) Reasonable pice and quick delivery
4. Main Technical Parameters.
1. Specification
(1) D3~D20mm.
(2) Super TiAlN coated
(3) 4 flute
(4) Micro Grain 0.5-0.6um
(5) Be made of Tungsten steel/ solid carbide.
(6) Different Grade with M SERIES(HRC45) & H SERIES(HRC55) & S SERIES(HRC62)
2. Application
* Suitable for machine tool steel, alloy steel, mold steel, carbon steel, cast steel and other highly hardened materials.
3. Advantage
(1) Be made by 5-AXIS tools grinding machine, guarantee the quality and precision first
(2) Each end mill is inspected by Zoller Machine
(3) OEM is available
(4) Can be customized per as your request
(5) Free samples for test
(6) Reasonable pice and quick delivery
4. Main Technical Parameters.
| M4EL(HRC45) | H4EL(HRC52) | S4EL(HRC62) | |||||
| Order No. | Order No. | Order No. | Size(mm) | ||||
| Dc | d | Lc | L | Fluet | |||
| M4EL03075S04 | H4EL03075S04 | S4EL03075S04 | 3 | 4 | 11 | 75 | 4 |
| M4EL04075S04 | H4EL04075S04 | S4EL04075S04 | 4 | 4 | 11 | 75 | 4 |
| M4EL05075S06 | H4EL05075S06 | S4EL05075S06 | 5 | 6 | 15 | 75 | 4 |
| M4EL06075S06 | H4EL06075S06 | S4EL06075S06 | 6 | 6 | 15 | 75 | 4 |
| M4EL03100S04 | H4EL03100S04 | S4EL03100S04 | 3 | 4 | 11 | 100 | 4 |
| M4EL04100S04 | H4EL04100S04 | S4EL04100S04 | 4 | 4 | 11 | 100 | 4 |
| M4EL05100S06 | H4EL05100S06 | S4EL05100S06 | 5 | 6 | 13 | 100 | 4 |
| M4EL06100S06 | H4EL06100S06 | S4EL06100S06 | 6 | 6 | 15 | 100 | 4 |
| M4EL08100S08 | H4EL08100S08 | S4EL08100S06 | 8 | 8 | 20 | 100 | 4 |
| M4EL10100S10 | H4EL10100S10 | S4EL10100S10 | 10 | 10 | 25 | 100 | 4 |
| M4EL12100S12 | H4EL12100S12 | S4EL12100S12 | 12 | 12 | 30 | 100 | 4 |
| M4EL14100S14 | H4EL14100S14 | S4EL14100S14 | 14 | 14 | 45 | 100 | 4 |
| M4EL06150S06 | H4EL06150S06 | S4EL06150S06 | 6 | 6 | 15 | 150 | 4 |
| M4EL08150S08 | H4EL08150S08 | S4EL08150S08 | 8 | 8 | 20 | 150 | 4 |
| M4EL10150S10 | H4EL10150S10 | S4EL10150S10 | 10 | 10 | 25 | 150 | 4 |
| M4EL12150S12 | H4EL12150S12 | S4EL12150S12 | 12 | 12 | 30 | 150 | 4 |
| M4EL14150S14 | H4EL14150S14 | S4EL14150S14 | 14 | 14 | 45 | 150 | 4 |
| M4EL16150S16 | H4EL16150S16 | S4EL16150S16 | 16 | 16 | 45 | 150 | 4 |
| M4EL18150S18 | H4EL18150S18 | S4EL18150S18 | 18 | 18 | 45 | 150 | 4 |
| M4EL20150S20 | H4EL20150S20 | S4EL20150S20 | 20 | 20 | 45 | 150 | 4 |
