Trolley Type 3D B/W Ultrasound Scanner (THR-US9902)

Trolley Type 3D B/W ultrasound scanner(THR-US9902)
High Quality Full Digital Ultrasound Scanner(THR-US9902)
High-precision Full Digital Image Technology
DBF Digital Beam-forming
RDA Real-time Dynamic Aperture
DRA Dynamic Receiving Apodization
DRF Dynamic Receiving Focusing
DFS Dynamic Frequency Scanning
THI Tissue Harmonic Imaging Technology
Clinical Application and Main Specification
Windows XP Embedded operation system
Three-Dimensional Imaging technology, rebuilt the 3D image from the 2D image.
Application: Abdomen, gynecology, obstetrics, urological small part and blood vessel. Automatic measurement software of OB/GYN, urology, pediatrics, cardiology and small parts. Select different diagnostic measurement formula for different race.
Imaging Mode: B, 2B, B/M, M, 4B
Doctor could get the perfect image by One-key Optimization setting
5000 static images and 100 dynamic images storage
Diagnostic report generated automatically, and printed out by A4 paper from laser printer.
Standard Configuration:
One 3.5 MHz Convex probe
15" LCD monitor
Three activated sockets
Windows XP System
Smart 8 sgements TGC adjustment
Measurement & calculation Software packages
Port: PAL-D, VGA, RS-232, USB2.0, DICOM3.0
1000 images built-in storage
Inside 3D software
Optional:
L6.5M/R10 Transvaginal Convex probe
L7.5M/L40 Linear probe
5.0 MHz Micro-Convex probe
7.5MHz Rectum Linear probe
Puncture Guide
Video Printer/ Inkjet printer/ Laser printer
140G/120G Hardware
HDD CD/DVD=RW
High Qualtity Images:
Our advantage for your informations:
1, Original Manufacturer, the producing workshop more than 40000 Square Meters;
2, All parts are produced by our factory;
3, Strict Material Inspection & Quality Controlling;
4, ISO9001, ISO13485(SGS) Quality Management System;
5, More than 10 years producing and engineering experience;
6, CE (SGS) Certificate;
7, Exported to more than 30 countries
