New Born Infant Breathing Machine

THR-AV-2000C New Born Infant Breathing Machine

Descriptions of THR-AV-2000C CPAP System Neonatal ventilator:
CPAP system is used for newborn baby with stronger spontaneous breath and slightly
Respiratory failure, and applies to pediatric clinics for NCPAP oxygen uptake


Features of CPAP System Neonatal ventilator:
1. CPAP ventilation mode keeps children spontaneous breath and reduces children breathing
Work, continues to provide CPAP mode of constant flow and limited pressure for new born
Baby;
2. Delivery air/ O2 mixture with properly adjusted O2 concentration and continuous positive
Pressure to premature baby, new born baby and child, which will highly improve the safety
And efficacy of oxygen therapy;
3. Equipped with built-in oxygen/ air blender, ensuring O2 concentration adjustment to be
Stable;
4. High quality oxygen sensor can monitor real-time O2 concentration, alarm over limitation,
Ensure safety of breathing O2;
5. Reliable CPAP control valve and advanced pressure monitoring system improve CPAP
Adjustment precision.
6.3'' display

Working condition:
Air source O2, AIR
Air source pressure 280kPa~600kPa
Power supply ~220V± 22V, 50Hz with air compressor
100-240V, 50/60Hz(without air compressor)
Input power 900VA(with air compressor)
250VA(without air compressor)

Technical Parameters of CPAP System Neonatal ventilator:

Gas supply
Gas source O 2 (For medical use) Air(For medical use)
Rated working pressure 350 kPa
Output pressure of regulator 350 kPa± 50 kPa (300 kPa ~400 kPa )

Power supply
Voltage ~220 V± 22 V
Frequency 50 Hz± 1 Hz
Input power 900A
— — Main unit 25
— — Air compressor 675 W
Internal power DC12V 4Ah
Fuse
— — AC power for main unit 5T T1AL 250
— — Battery 5T T2AL 250V
— — AC power for air compressor 5T T6.3AL 250V
— — AC power for machine 5T T10AL 250V

Parameter adjustment
FiO2
— — Adjusting range 21 %~100 %
— — Accuracy ± 15 %
CPAP adjusting range 0 CMH 2 O ~15 CMH2 O
Continuous flow adjusting range 2 L/min ~20 L/min
Continuous flow adjusting range for manual 20 L /min± 5L/min

Parameter monitoring
FiO2
— — Adjusting range 15 %~100 %
— — Accuracy ± 5 %
CPAP/airway pressure
— — Monitoring range 0 CMH2 O ~60 CMH2O
— — Accuracy ± (2%fullscale +4 % actual value)
Continuous flow
— — Monitoring range 2 L/min~20 L/min
— — Accuracy ≥ 3 L/min: ± 20 %
Waveform display:
— — Airway pressure— Time waveform

Technical specification of compressor
Rated output pressure: 0.35 MPa± 0.05 MPa(350 kPa± 50 kPa)
Continuous output flow ≥ 25 L/min when output pressure is 0.35MPa
Peak flow: ≥ 120 L/min
Dew point temperature ≤ -10° Cwhen Atmospheric pressure is 860 hPa ~1060hPa
Alarm for high heat: There is sound alarm and light alarm when the compressed pump temperature is over 85 ° C± 10 ° C
Noise ≤ 50 dB(A)
