Vertical Form Fill Seal Machine

The Wrapping machine(VFFS-150) otherwise know as a Bag Maker (VFFS), is a part of an automated packaging system. Commonly used in the packaging of food and a wide range of products.

How It Works?

 1,The bagging process begins, when the film is pulled down by a cam driven, horizontal jaw. The printed film is wrapped around the outside of a long hollow conical tube, so a tube is formed and the outer edges of the film form a flap.

2, The seam edges, need bonding, so the vertical heat sealing bar clamps the film flaps and melts the seam edges together, creating a tube.

3,Then a horizontal sealing bar clamps the bottom edge of the tube, bonding the film together. Once the bottom of the bag is sealed it's ready to be filled through the long conical tube, know as (Forming Tube).

4, When the bag is formed and the bottom edge is sealed a signal is sent to the dosing device indicating it's ready for product. This product is delivered through the forming tube, into the bag.

5,Your bag is then indexed to correct length and horizontal jaws cut the bag off from the tube. It's now a sealed package, ready to move your product to boxing and shipping processes. The feeding of material and cutting of the pouch can be determined by length, or indexing via mark, which is detected by our built-in Optical Registration Sensor

Our Services: Overseas Service Center Available

1, 12 months parts and labor is warranted on all equipment supplied by C.W.E.

2, A.W.E Group recognises that providing great service, with great people on time.
3,Our company is committed to providing quality, reliable products, customer service and support.

Comparison Chart of Our Wrapping machine(VFFS-150)
