Spin Welder

Spin Welding Process AdvantagesAbility to weld parts with circular joint that are not easily welded by ultrasonics.Relatively fast cycle times when compared with other methods.Compatible with most thermoplastics.Ideal for welding of PP and PE materials.Ability to weld several dissimilar materials.No consumables, fumes or emissions.High strength, hermetic welds are typical.Heat confined to weld interface.Easily automated.Low cost, quick change tooling.Low maintenance.Low power consumption.Spin Welding is a frictional welding technique capable of producing strong, air-tight welds in thermoplastic parts with a circular-axis joint.In this process, friction occurs by rotational motion controlled by either a servo electro-magnetic or pneumatic powered motor and motor control systemWhich regulates the RPM (Revolutions Per Minute) and motion control of the system.Friction is achieved through motion between two parts, one is held stationery, the other rotating at a controlled RPM (typically 200-5, 000 RPM) whileClamped under pressure. Melt occurs only at the interface of the joint area of the plastic part halves. The part is cooled under pressure and permitted toSolidify.Common stand column spin welderSize: L1260*W1125*H1960mmSlide board size: L420*W420mmWeight: 1300KgPneumatic parts: Up and dowm cylinder DNC-125-150-PPV-A\forward and back cylinder DSNU-25-320-PPV-A\safeCylinder AND-32-30-I-P-A(FESTO)
