Carbonated Drink Filling Machine Monoblock

DCGF60-60-15 Carbonated beverage filling machineDGCF60/60/15 washing, filling, capping machine is used for PET bottles, And carbonated beverage of special equipment, unique clamping bottle fillingTechnology, frequency control, automatic tank level control, equal pressure Filling, etc. It adopts constant pressure into the fluid, and match the mixer Main technical parameters: 1) Model: DGCF60-60-152) capacity: 18000BPH(500ml)8000BPH(1500ml) 5000BPH(2000ml)3) Filling valve: 604) Rinsing head: 605) Capping head: 156) Suitable for bottle volume: Φ 50~Φ 110mm7) Suitable for bottle height: 150-320mm8) Pressure of compressed air: 0.4-0.6MPaAir consumption: 8-10m3/h9) Rinsing PET bottle media: Sterile water 10) Washing bottle time: 3-5S11) Drying time: About 3-5 S12) Water pressure of washing bottle: 0.25MPaWater consumption: 8-10m3/h13) General water consumption: About 1-2.5 m3/h14) Motor: About 13KW AC380V15) Control: DC24V16) Height of conveyor belt working: 1200ml17) Dimension: (LXWXH)~6500X3400~3300mm18) Weight: About 12000kgMain configuration: 1. Sensor: Mitsubishi/Omron(Japan)2. PLC: Mitsubishi/Omron(Japan)3. AC Contactor: Mitsubishi(Japan)4. Transformer: Delixi5. Proximity Switch: Delixi6. Pneumatic Components: Taiwan Airtac7. Touch Screen: Mitsubishi8. Reducer: Shanghai9. Breaker: DelixiCertification: CE&ISO9001 Rinsing partFilling part
