YX25-200-1000 Tile Roll Forming Machine
1. Brief introduction:
A. Simple structure and beautiful outlook;
B. Easy to setting and operation
C. Little noise and high working efficiency.

2. Main technology parameter:
1. Size of the machine: About (length*width*height) 8500mm*1700mm*1400mm
2. Main power: 5.5Kw
3. Forming speed: About 5-6m/min
4. Thickness of formed steel: About 0.4mm-0.7mm
5. The available width of formed steel tile: 1000mm
6. The width of raw material: 1200mm
7. Roll station: 15 stations
8. Material of the roller: 45#forge steel, machined with numerical control, polished and coated with chrome, surface with 0.05mm
9. Material of blade: Cr12, quenched 58-62
10. Diameter of roller: 70mm
11. Hydraulic oil pump: 5.5KW
12. Computer adopts PLC, Panasonic
13. Converter: Panasonic
14. Computer operating board: LCD touch screen.
