Yx41-320-960 Roll Forming Machine

Get Latest Price

Payment Type:: L/C, T/T, Money Gram, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Suzhou, China
Payment Type:	L/C, T/T, Money Gram, Western Union

Product Description

Details of each compostion:

A: Roll forming main machine
1: Coil width: 1220mm effective width: 960±3mm
2: working speed: 12m—15m/min (not contain cutting)
3: roll station: about 25 stations
4: material of roller: Gcr15, CNC lathes, hard Chrome Coated with hear treatment 58-62 degree.
5:material of main shaft:45forge steel diameter roller: 76mm
6: main power: 15kw(7.5kw×2) adopt China famous brand
7: forming thickness: 0.4-0.8mm color steel and galvanized steel345Mpa-550Mpa
8: feeding and guide: adopt hand wheel to easy adjust the feeding width, the machine should be adopt maximal feeding width in 1250mm
10: Transmission: by 1.0 inch double chain should be adopt import famous brand
11: Machine with edge trimmer (both sides): power in 3KW per each one motor
12: For forbid the two lip waviness, the machine should be adding side rollers to forbid this problem in the future.
Yx41-320-960 Roll Forming Machine
