Door Shutter Roll Forming Machine

Get Latest Price

Payment Type:: L/C, T/T, Money Gram, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu, China
Payment Type:	L/C, T/T, Money Gram, Western Union

Product Description

Details of each composition

Punching machine

1. Machine adopts 25Tons punching machine
2. Feeding by air pneumatic
3. Air pneumatic power: 3KW (provide by buyer)
4. Punching mold: Cr12 with heat treatment

Roll forming main machine

1: coil width: 171mm, effect width: 120mm

2: working speed: 12m—15m/min (not contain cutting)
3: roll station: about 15 stations
4: material of roller: 45#forge steel, polished and coated with chrome
5: material of main shaft:45#forge steel diameter roller: 56mm
6: main power: 5.5kw
7: forming thickness: 0.4-0.8mm color steel and galvanized steel up to 235mpa
8: Transmission: by Chains 1 inch
9: machine adopt wall board structure
10: Cutting:

(1) Machine adopts fly saw cutting

(2)   Cutting after forming: Cut the sheet after roll forming to required length
(3)   Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.
(4)   Material of blade: HSC with heat treatment

(5) Length measuring: Automatic length measuring

(6) Tolerance of length: 3m+/- 1.5mm
