Hydraulic Decoiler with Coil Car

Get Latest Price

Payment Type:: L/C, T/T, Money Gram, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu, China
Payment Type:	L/C, T/T, Money Gram, Western Union

Product Description

Brief introduction:
A: Simple structure and beautiful outlook;
B: Easy to setting and operation
C: Little noise and high working efficiency.

Main technology parameter:
Single unrolling machine, one side can put material
Adopt automatic hydraulic system
Coil weight (Max): 10000kg
Inter diameter: 470mm-620mm
Maximal out diameter: 1600mm
Oil cylinder dia: 120mm
Coil width (Max. )1300mm
Working speed: 0-30m/min
Power: 7.5KW AC motor
Hydraulic power: 5.5kw
De-coiler should be with Loop control and hold down
Coil car: 10Tons
The coil car by hydraulic: 16Mpa
Pressure: 12-20Mpa
The decoiler have four segments
