Product Description

Main technology parameter:
1: Coil width: 254mm
2: Working speed: 20m/min (not contain punching and cutting)
3: Roll station: 24stations (include 7 stations for leveling sheet)
4: Material of roller: 45#forge steel, polished and coated with chrome
5: Material of main shaft: 45forge steel diameter roller: 76mm
6: Main power: 18.5kw
7: Forming thickness: 1.5mm-3mm
8: Transmission: By Chains
9: Cutting:
(1)Adopt hydraulic cutting
(2)Cutting after forming: Cut the sheet after roll forming to required length
(3)Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.
(4)Material of blade: CR12with heat treatment
(5)Length measuring: Automatic length measuring
(6)Tolerance of length: +/- 1.5mm
Shelf Roll Forming Machine
